337m 8000L/H 7.5HP solar submersible pump specifications
Model: WHC 4/52-5.5/7.5HP Solar Submersible Pump
Max head rate: 337m
Max flow rate: 8000L/H
Solar panels: high-efficiency mono silicon solar panels
Pure copper motor power: 5500W
Mppt router: 7500W
Solar input voltage: 560V
Open circuit voltage (Voc): 750v
Working time:During the sunshine
Pump material: 304 stainless steel
268m 8000L/H 5.5HP solar submersible pump specifications
Model: WHC 4/48-4/5.5HP Solar Submersible Pump
Max head rate: 268m
Max flow rate: 8000L/H
Solar panels: high-efficiency mono silicon solar panels
Pure copper motor power: 4000W
Mppt router: 5500W
Solar input voltage: 560V
Open circuit voltage (Voc): 750v
Working time:During the sunshine
Pump material: 304 stainless steel
206m 8000L/H 4HP solar submersible pump specifications
Model: WHC 4/32-3/4HP Solar Submersible Pump
Max head rate: 206m
Max flow rate: 8000L/H
Solar panels: high-efficiency mono silicon solar panels
Pure copper motor power: 3000W
Mppt router: 4000W
Solar input voltage: 560V
Open circuit voltage (Voc): 750v
Working time:During the sunshine
Pump material: 304 stainless steel
151m 8000L/H 3HP solar submersible pump specifications
Model: WHC 4/22-2.2/3HP Solar Submersible Pump
Max head rate: 151m
Max flow rate: 8000L/H
Solar panels: high-efficiency mono silicon solar panels
Pure copper motor power: 2200W
Mppt router: 3000W
Solar input voltage: 560V
Open circuit voltage (Voc): 750v
Working time:During the sunshine
Pump material: 304 stainless steel
110m 8000L/H 2HP solar submersible pump specifications
Model: WHC 4/18-1.5/2HP Solar Submersible Pump
Max head rate: 110m
Max flow rate: 8000L/H
Solar panels: high-efficiency mono silicon solar panels
Pure copper motor power: 1500W
Mppt router: 2200W
Solar input voltage: 560V
Open circuit voltage (Voc): 750v
Working time:During the sunshine
Pump material: 304 stainless steel
101m 8000L/H 1.5HP solar submersible pump specifications
Model: WHC 4/14-1.1/1.5HP Solar Submersible Pump
Max head rate: 101m
Max flow rate: 8000L/H
Solar panels: high-efficiency mono silicon solar panels
Pure copper motor power: 1100W
Mppt router: 1500W
Solar input voltage: 330V
Open circuit voltage (Voc): 500v
Working time:During the sunshine
Pump material: 304 stainless steel
72m 8000L/H 1HP solar submersible pump specifications
Model: WHC 4/10-0.75/1HP Solar Submersible Pump
Max head rate: 72m
Max flow rate: 8000L/H
Solar panels: high-efficiency mono silicon solar panels
Pure copper motor power: 750W
Mppt router: 1100W
Solar input voltage: 160V
Open circuit voltage (Voc): 230v
Working time:During the sunshine
Pump material: 304 stainless steel
58m 8000L/H 0.75HP solar submersible pump specifications
Model: WHC 4/8-0.55/0.75HP Solar Submersible Pump
Max head rate: 58m
Max flow rate: 8000L/H
Solar panels: high-efficiency monoc silicon solar panels
Pure copper motor power: 550W
Mppt router: 750W
Solar input voltage: 160V
Open circuit voltage (Voc): 230v
Working time:During the sunshine
Pump material: 304 stainless steel
WHC 8000L 0.75 to 7.5HP 58 to 337m submersible AC solar irrigation system
WHC SOLAR 8000L AC brushless solar irrigation system. In operation, 8,000 liters per hour is equivalent to 8 tons, and the power of different models can meet the requirements of different users. No matter what kind of water demand, WHC SOLAR 8000L series solar water pump can provide a complete water supply system.
Main structure of the AC solar water pump system consists of three parts:
Monocrystalline solar panel: It is composed of solar energy collection and photoelectric conversion device, which absorbs solar energy and converts it into energy (electricity); the solar water pump adjusts the output power in real time according to the change of sunlight intensity to drive the water pump to ensure that each solar panel can have Sufficient power output. Its service life is more than 20 years, and the warranty is 10 years.
Solar water pump inverter/controller (VFD): convert the energy generated by solar panels into electrical energy; track the output of the photovoltaic array through the maximum power point to drive the pump motor to the greatest extent. In addition to the DC input of the photovoltaic array, the special inverter for solar water pumps also supports AC input. When the output of the photovoltaic array cannot drive the motor or has no output, it also accepts the AC input of the grid to meet various emergency needs. The special inverter for solar water pumps provides all-round protection functions such as overcurrent, undervoltage, and leakage prevention to maximize the service life of the motor and solar water pump.
Water pump motor: The whole water pump motor is made of 304 stainless steel, which has the characteristics of anti-rust, corrosion resistance, long life, high compressive strength, etc., thereby reducing its own net weight, lighter weight, easy to use, and suitable for a wider range of industries. The outer shell of the stainless steel water pump wraps the main shaft and impeller of the water pump, and is an important part of the pump motor.
Main features and advantages of solar irrigation pumps:
1. The solar irrigation pump is easy to install and maintenance-free
2. The motor and water pump are integrated, energy-saving, high-efficiency, safe and reliable
3. Light weight, no noise, no pollution, it has a strong effect on improving the installation environment
4. Equipped with stainless steel submersible motors produced by advanced technology, rust-proof and corrosion-resistant
5. The inverter is well-designed and safer to use
6. Wide input voltage range, suitable for a variety of photovoltaic modules
7. Both solar and city electricity can be put into operation
8. Factory direct sales, the price is more favorable.
Application of AC submersible solar farm pumping system
Solar agricultural pump systems are used for farm irrigation, aquaculture farms, livestock drinking water, deep wells, rivers, ponds, homes, villages, government projects, etc.
